The Novawinch HEN30000, a robust member of the HEN MAX series, is a top-tier 30,000lb (13,608kg) EN-rated hydraulic winch designed for demanding tasks. Featuring a manual clutch, this powerful winch is the ultimate solution for heavy recovery rotators, mining operations, and military vehicles. Its lever-operated clutch system ingeniously removes the need for an onboard air compressor, while IP67 protection and a sophisticated multi-disc brake guarantee exceptional performance and durability in extreme conditions.
Engineered for professionals who demand unwavering reliability, the HEN30000 hydraulic winch delivers an impressive first-layer line pull of 30,000 lb (13,608 kg). Achieve a swift line speed of 15.1 fpm (4.6 m/min) with an optimal 70 l/min oil flow. Key technical specifications include a working pressure of 2,465 psi (17 MPa) and an efficient gear ratio of 30.39:1. The integrated manual clutch ensures precise control and dependable engagement, even in the most remote and challenging environments.
The HEN30000's manual clutch prioritises mechanical reliability, eliminating the complexity and potential failure points associated with air compressors. Its lever operation provides fail-safe engagement with clear positive feedback, making it indispensable for vehicles without pneumatic systems or where operational simplicity is paramount for heavy-duty winching.
This industrial hydraulic winch boasts oversized cast steel drum supports, hardened planetary gears, and a sturdy carbon steel tie bar, ensuring unmatched structural integrity when handling 13.6-tonne pulls. GV-12 threads provide leak-resistant oil connections, while the advanced multi-disc brake and IP67-rated seals ensure reliable operation through mud, rain, or grit, making it a truly all-weather winch.
For optimal performance, an 18 mm (3/4") wire rope is recommended, offering a drum capacity of 170.6 ft (52 m) across 5 layers. The rated line pull and line speed dynamically adjust by layer; for instance, layer 5 provides 17,728 lb of pull and a speed of 24.3 fpm, fully utilising the 170.6 ft capacity. For comprehensive performance data, consult the detailed Performance table in the Specifications.
Important Note: This Novawinch hydraulic winch requires a dedicated hydraulic power source. For optimal performance and longevity, an independent oil supply equipped with a relief valve is also strongly recommended.
| Layer | Rated Line Pull | Line Speed | Wire Rope Capacity |
|---|---|---|---|
| 1 | 30,000 lb (13,608 kg) | 15.1 fpm (4.6 m/min) | 22.9 ft (7 m) |
| 2 | 25,578 lb (11,600 kg) | 17.4 fpm (5.3 m/min) | 52.5 ft (16 m) |
| 3 | 22,288 lb (10,108 kg) | 19.7 fpm (6.0 m/min) | 91.8 ft (28 m) |
| 4 | 19,750 lb (8,957 kg) | 22 fpm (6.7 m/min) | 134.5 ft (41 m) |
| 5 | 17,728 lb (8,040 kg) | 24.3 fpm (7.4 m/min) | 170.6 ft (52 m) |
| Manufacturer | Novawinch |
|---|---|
| Winch Type | Hydraulic Recovery Winch |
| First Layer Line Pull | 30,000 lb (13,608 kg) |
| First Layer Line Speed | 15.1 fpm (4.6 m/min) |
| Working Pressure Differential | 2,465 psi (17 MPa) |
| Oil Flow Supply | 70 l/min (Recommended range: 35–90 l/min) |
| Gear Ratio | 30.39:1 |
| Wire Rope Dimensions | 18 mm (3/4") x 170.6 ft (52 m) |
| Rope Layers | 5 |
| Clutch Type | Manual (Lever) |
| Net Weight (Excl. Rope) | 573 lb (260 kg) |
| Installation Note | Independent oil supply system with relief valve is recommended. |
