Introducing the NOVAWINCH HW200 45,000lb (20,412kg) Military-Rated Hydraulic Winch, engineered for the toughest industrial and defense applications. Unlike standard commercial units, the HW Series is designed for "mission-critical" environments, delivering uncompromising strength and durability for military tactical vehicles and heavy commercial recovery trucks.
The HW200 performs under the most demanding conditions, featuring a heavy-duty hydraulic system capable of sustained high-load pulls without overheating. Crucially for UK and European operators, the HW200 is fully compliant with EN14492-1:2006 requirements, guaranteeing rigorous safety and efficiency standards for fleet managers and safety officers.
| Layer | Rated Line Pull | Line Speed (Normal) | Wire Rope Capacity |
|---|---|---|---|
| 1 | 45,000 lb (20,412 kg) | 11.5 fpm (3.5 m/min) | 39 ft (12 m) |
| 2 | 39,277 lb (17,816 kg) | 12.5 fpm (3.8 m/min) | 85 ft (26 m) |
| 3 | 34,846 lb (15,806 kg) | 14.1 fpm (4.3 m/min) | 137 ft (42 m) |
| 4 | 31,313 lb (14,203 kg) | 15.7 fpm (4.8 m/min) | 196 ft (60 m) |
| Manufacturer | Novawinch |
|---|---|
| Winch Type | 2-Speed Hydraulic Recovery Winch |
| First Layer Line Pull | 45,000 lb (20,412 kg) |
| First Layer Line Speed | Normal: 11.5 fpm (3.5 m/min) High: 49 fpm (15 m/min) |
| Working Pressure Differential | 2,465 psi (17 MPa) |
| Oil Flow Supply | 70 l/min |
| Gear Ratio | 84:1 |
| Wire Rope Dimensions | 22 mm (7/8") x 196 ft (60 m) |
| Rope Layers | 4 |
| Valve Model | NF-120 P1 S1-003 |
| Net Weight (Excl. Rope) | 948 lb (430 kg) |
