The Novawinch HEN25000, the ultimate heavy-duty hydraulic winch in the HEN MAX series, boasts an EN-rated certification and a formidable 25,000 lb (11,340 kg) capacity. Engineered for the most demanding heavy recovery operations, it's the ideal hydraulic winch for wreckers, military vehicles, and low-loaders. Standard features include a pneumatic clutch, IP67 protection, and a robust multi-disc brake. Enjoy peace of mind with a 12-month warranty and free next-day delivery.
The HEN25000 winch is meticulously engineered for maximum capability in challenging industrial applications, including heavy recovery wreckers and low-loaders. It delivers an impressive first-layer line pull of 25,000 lb (11,340 kg) and a swift line speed of 18 fpm (5.5 m/min) at 70 l/min oil flow. Key specifications include a working pressure of 2,465 psi (17 MPa)and a gear ratio of 20.0:1.
A pneumatic clutch comes standard, enabling convenient air-controlled engagement directly from the cab. For secure, leak-resistant oil hose connections, this hydraulic recovery winch features GV-12 threads. Structural integrity is paramount, ensured by oversized cast steel drum supports, hardened planetary gears, and a sturdy carbon steel tie bar. The advanced multi-disc brake and IP67-rated seals guarantee reliable operation in extreme environments such as quarries, construction sites, and severe weather.
For optimal performance, we recommend using 16 mm (5/8") wire rope, which allows for a drum capacity of 131 ft (40 m) across four layers. The rated line pull and line speed vary by layer; please consult the Performance table in the Specifications for comprehensive details (e.g., layer 4: 16,176 lb, 27.8 fpm, 131 ft capacity).
Please note: This heavy-duty hydraulic winch requires a hydraulic power source; an independent oil supply with a relief valve is highly recommended for optimal performance and safety.
| Layer | Rated Line Pull | Line Speed | Wire Rope Capacity |
|---|---|---|---|
| 1 | 25,000 lb (11,340 kg) | 18 fpm (5.5 m/min) | 25 ft (7.6 m) |
| 2 | 21,100 lb (9,571 kg) | 21.3 fpm (6.5 m/min) | 52.3 ft (15.9 m) |
| 3 | 18,500 lb (8,394 kg) | 24.5 fpm (7.5 m/min) | 91.7 ft (27.9 m) |
| 4 | 16,176 lb (7,339 kg) | 27.8 fpm (8.5 m/min) | 131 ft (40 m) |
| Manufacturer | Novawinch |
|---|---|
| Winch Type | Hydraulic Recovery Winch |
| First Layer Line Pull | 25,000 lb (11,340 kg) |
| First Layer Line Speed | 18 fpm (5.5 m/min) |
| Working Pressure Differential | 2,465 psi (17 MPa) |
| Oil Flow Supply | 70 l/min (Recommended range: 35–90 l/min) |
| Gear Ratio | 20.0:1 |
| Wire Rope Dimensions | 16 mm (5/8") x 131 ft (40 m) |
| Rope Layers | 4 |
| Clutch Type | Pneumatic |
| Air Pressure Range (Clutch) | 1–8 bar |
| Ventilation Volume | 1 L/min |
| Net Weight (Excl. Rope) | 359.4 lb (163 kg) |
| Installation Note | Independent oil supply system with relief valve is recommended. |
