Unleash the full potential of your heavy operations with the Novawinch HEN45000 45,000lb (20,412kg) EN Rated Hydraulic Winch. As the powerhouse of the 'HEN MAX' Series, this heavy-duty hydraulic winch is engineered for professionals who demand unparalleled strength and reliability. This Standard Drum winch offers a massive 20-tonne pulling capacity while maintaining a footprint that integrates easily into standard heavy wrecker chassis and industrial mounting plates.
The HEN45000 prioritises operational efficiency with its standard pneumatic clutch. Unlike manual systems, this air-actuated clutch allows for seamless, remote engagement from the cab, ensuring faster operation times and keeping the operator at a safe distance during heavy wire rope tensioning.
Built to withstand the rigors of the UK's toughest environments, this industrial hydraulic winch features oversized casting steel drum supports, hardened planetary gears, and a reinforced carbon steel tie bar.
| Layer | Rated Line Pull | Line Speed | Wire Rope Capacity |
|---|---|---|---|
| 1 | 45,000 lb (20,412 kg) | 12.5 fpm (3.8 m/min) | 25.2 ft (7.6 m) |
| 2 | 37,266 lb (16,903 kg) | 14.8 fpm (4.5 m/min) | 53.1 ft (16.2 m) |
| 3 | 31,800 lb (14,424 kg) | 17.1 fpm (5.2 m/min) | 82.6 ft (25.2 m) |
| 4 | 27,733 lb (12,579 kg) | 19.4 fpm (5.9 m/min) | 111.5 ft (34 m) |
| Manufacturer | Novawinch |
|---|---|
| Winch Type | Hydraulic Recovery Winch |
| First Layer Line Pull | 45,000 lb (20,412 kg) |
| First Layer Line Speed | 12.5 fpm (3.8 m/min) |
| Working Pressure Differential | 2,465 psi (17 MPa) |
| Oil Flow Supply | 85 l/min (Recommended range: 40–90 l/min) |
| Gear Ratio | 30.4:1 |
| Wire Rope Dimensions | 22 mm (7/8") x 111.5 ft (34 m) |
| Rope Layers | 4 |
| Clutch Type | Pneumatic |
| Air Pressure Range (Clutch) | 1–8 bar |
| Ventilation Volume | 1 L/min |
| Net Weight (Excl. Rope) | 595 lb (270 kg) |
| Installation Note | Independent oil supply system with relief valve is recommended. |
