The Novawinch HEN30000 is a premier EN-rated hydraulic winch from the HEN MAX series, engineered for extreme performance with a 30,000lb (13,608kg) capacity. This robust hydraulic winch is the ultimate choice for heavy recovery rotators, mining applications, and military vehicles, where reliability is paramount.
Designed for professionals who cannot afford equipment failure, the HEN30000 delivers exceptional power. It boasts a first-layer line pull of 30,000 lb (13,608 kg) and a line speed of 15.1 fpm (4.6 m/min) at an optimal 70 l/min oil flow. Operating at a working pressure of 2,465 psi (17 MPa) with a gear ratio of 30.39:1, this heavy-duty hydraulic winch is perfectly suited for demanding tasks with heavy recovery rotators, mining vehicles, and military transporters.
The integrated pneumatic clutch allows for remote engagement and disengagement directly from the cab or control station, eliminating the need for manual interaction with the drum. This feature, operating with an air pressure of 1–8 bar and requiring 1 L/min air consumption, ensures faster operation and enhanced safety by keeping the operator clear of the winch during spooling. It's an ideal solution for vehicles equipped with onboard air systems.
Built for extreme durability, the Novawinch HEN30000 features oversized cast steel drum supports, hardened planetary gears, and a carbon steel tie bar to maintain structural integrity under intense 13.6-tonne pulls. GV-12 threads guarantee leak-resistant oil connections, while the multi-disc brake and IP67-rated seals ensure reliable operation in challenging environments, including mud, rain, and grit.
The recommended 18 mm (3/4") wire rope has a drum capacity of 170.6 ft (52 m), distributed across 5 layers. It's important to note that the rated line pull and line speed vary significantly by layer. Comprehensive details can be found in the Performance table within the Specifications; for example, layer 5 demonstrates a 17,728 lb pull and 24.3 fpm speed, with a total drum capacity of 170.6 ft.
Please note: Operation requires a hydraulic power source and a vehicle air system for the pneumatic clutch. An independent oil supply with a relief valve is also recommended for optimal performance.
| Layer | Rated Line Pull | Line Speed | Wire Rope Capacity |
|---|---|---|---|
| 1 | 30,000 lb (13,608 kg) | 15.1 fpm (4.6 m/min) | 22.9 ft (7 m) |
| 2 | 25,578 lb (11,600 kg) | 17.4 fpm (5.3 m/min) | 52.5 ft (16 m) |
| 3 | 22,288 lb (10,108 kg) | 19.7 fpm (6.0 m/min) | 91.8 ft (28 m) |
| 4 | 19,750 lb (8,957 kg) | 22 fpm (6.7 m/min) | 134.5 ft (41 m) |
| 5 | 17,728 lb (8,040 kg) | 24.3 fpm (7.4 m/min) | 170.6 ft (52 m) |
| Manufacturer | Novawinch |
|---|---|
| Winch Type | Hydraulic Recovery Winch |
| First Layer Line Pull | 30,000 lb (13,608 kg) |
| First Layer Line Speed | 15.1 fpm (4.6 m/min) |
| Working Pressure Differential | 2,465 psi (17 MPa) |
| Oil Flow Supply | 70 l/min (Recommended range: 35–90 l/min) |
| Gear Ratio | 30.39:1 |
| Wire Rope Dimensions | 18 mm (3/4") x 170.6 ft (52 m) |
| Rope Layers | 5 |
| Clutch Type | Pneumatic |
| Air Pressure Range (Clutch) | 1–8 bar |
| Ventilation Volume | 1 L/min |
| Net Weight (Excl. Rope) | 573 lb (260 kg) |
| Installation Note | Independent oil supply system with relief valve is recommended. |
